| 製品名： V20 inside Ф8mm lens | |
| UP-V20N8 Angle：25° dimension：Ф20mm Material：optical PMMA |
|
|
|
UP-V20N8
Angle：25°
dimension：Ф20mm
Material：optical PMMA
HOLDER：ABS OR PC （black or white color）
Endure temperature：-40deg C / +80deg C
LED series：lumileds、Z-power、Edison、helio、everlight、prolight、harvatek、nichia …
Characteristic：
1 Using entire reflection cup lens and clear surface design, issued by the LED light condenser results can be achieved more than 90% (3 mm thickness at 93% penetration);
2 Lens 8.0 mm in diameter, the lens can not support direct fastening assembly in the high-power LED, the lens can also be
used to fix the stent;
3 Effectively overcome some of the yellow halo LED spot phenomenon ,facula concentrated, high brightness, and no stray
light, no black hole, no shadow or dark areas;
4 The type of lens particularly with the LED of Z-Power relatively is good condenser effects (lens direct fastening in the
LED of Z-Power );
5 products using high-precision aspheric optical design and use of Japan's Mitsubishi original PMMA optics imports of raw
materials to ensure adequate time for injection molding (reducing shrinkage products), anti-static products using PVC
packaging, all products are certified by SGS and comply with ROHS environmental requirements.
Application：
Widely used in infrared surveillance, PAR lamps, projector lamps, underwater lights, courtyard landscape lights,
