| 製品名： V12H-JT75 | |
| UP-V12H-JT75 Angle：75° Dimension：Ф12 Material：optical PMMA |
|
|
|
UP-V12H-JT75
Angle：75°
Dimension：Ф12
Material：optical PMMA
Endure temperature：-40deg C / +80deg C
LED series：CREE XP 3535
Characteristic：
1 Many lens and fixed holder completed by injection into a whole (LED lens module), divide trinity or five-in-one.
2 Using entire reflection Cup lens design, issued by the LED light condenser results can be achieved more than 90% (3 mm thickness at 93% penetration);
3Three (Or five) of the LED light through the LED facula after the condenser lens module can be completely overlap with a significant increase in facula intensity;
4 Lens surface of a matrix, changing light show direct and diffuse type, lighting softnees and not dazzling lighting, RGB color-mixing more beautiful and true;
5 Effectively overcome some the dizzy yellow white light LED facula phenomena;
6 The three LED module lens distance closer to the center, lens module maximum diameter of 35 mm or 43 mm, and that effective space-saving lamps do more compact lamps;
7 The products use high-precision aspheric optical design and use of Japan's Mitsubishi original PMMA optics imports of raw materials to ensure adequate time for injection molding (reducing shrinkage products), anti-static products using PVC packaging, all products are certified by SGS environmental requirements and comply with RoHS.
Application：
Widely used wall washing light,projection lamp,floddlight,led cup lamp,ceiling light,rainbow lamp,lawn light, underwater lights, underground led light...etc.
