| Name:LX65135 lens | |
| UP-LX65135
Angle：65 * 135° Dimension：17*9mm Material：optical PMMA |
|
|
|
UP-LX65135
Angle：65 * 135°
Dimension：17*9mm
Material：optical PMMA
Endure temperature：-40deg C / +80deg C
LED series：：CREE XP OR“3535”
Characteristic：
1 it is aspherical optical design, its effect of condensing the light issued by LED light can reach above 90%; ( 3mm thickness at 93% penetration )
2 lit is designed for high power LED lamp ,angle is 65 * 135°, its facula is uniform, it is designed for CREE XP, it can also be applied to 3535 LED;
3 it has embedded and bonded design, there are two plastic plastic pillars at the bottom of a lens, which can extend into PCB to position and fix, the lens can also be fixed by glue on the bottom.
4 on both sides of the lens there are two protruding block, it is designed for the light to fix well;
5 beside the lens, there is a bounding edge around it, the design is beautiful and it offer the lamp with waterproof structure;
6The lens uses high-precision aspheric optical design and is made of Japanese Mitsubishi original PMMA optics material, we keep adequate time for injection molding (reducing shrinkage products), and use anti-static PVC packaging, all lenses are certified by SGS environmental requirements and are complied with RoHS.
Application：
Widely used in high-power LED street lamps, tunnel lights.
